Product name

 S100-11B+TH10 Micro flow Peristaltic Pump

Pump head

TH10A(4 Roller),TH10B(8 Roller)

CPU

ARM Cortex-0 Core,STM32 Chip

Motor drive chip

THB6128 SANYO drive chip

Start/Stop

Control Start/Stop

Direction control

Clockwise and anticlockwise direction reversible

Internal speed control

BCD DIP switch adjustable

External speed control

0-10kHz impulse control, or 0-5V,0-10V,4-20mA analog signal control for choice, 0-10KHz for standard

Internal speed control range

1-100rpm, 15 levels adjustable, standard configuration: 5,10,15,20,25,30,35,40,45,50,60,70,80,90,100rpm

Customize service support

External speed range

0-100rpm, speed resolution 0.1rpm, colinearity

Communication control

RS485 communication, Modbus communication protocol, communication control can’t be exist together with other external control

Speed deviation

≤±0.5%

Tube available

0.6×1，1×1,2×1，2.4×0.8，3×1，0.38×0.86，0.76×0.86，1.02×0.86，1.6×0.8，2.06×0.86，2.79×0.86，3.17×0.86，3.2×0.8

Stop/Start

Press and adjust the switch spot to run the peristaltic pump; close switch spot(port 5&port 7 short circuit) to shut down the pump

Direction control

Switch control the touch pot for start operation, peristaltic pump run; close switch spot(port 5&port 7 short circuit), peristaltic pump run at anticlockwise direction

Power supply

11.4-25.2V DC；or 100-240V AC（match different power adapter）  50/60Hz

Operation condition

temperature:0℃-40℃, Relative humidity: ＜80%

Weight

640g
