Product name

S100-2B+DG Micro flow Peristaltic Pump

Pump head

DG-1A(6 roller),DG-1B(10 roller)， DG-2A(6 roller),DG-2B(10 roller)，DG-4A(6 roller)，

DG-4B(10 roller)， DG-6A(6 roller)，DG-6B(10 roller)

Start/Stop control

support

Direction control

Clockwise and anticlockwise reversible

Internal speed control

BCD DIP switch adjustable

External speed control

0-10kHz impulse control, or 0-5V,0-10V,4-20mA analog signal control for choice, 0-10KHz for standard

Internal speed  range

1-100rpm, 15 levels, standard configuration: 5,10,15,20,25,30,35,40,45,50,60,70,80,90,100rpm; customize support

External speed range

0-100rpm, speed resolution 0.1rpm, colinearity

Communication control

RS485 communication, Modbus communication protocol, communication control can’t be exist together with other external control

Speed deviation

≤±0.5%

Tue available

0.6×1，1×1,2×1，2.4×0.8，3×1，0.38×0.86，0.76×0.86，1.02×0.86，1.6×0.8，2.06×0.86，2.79×0.86，3.17×0.86，3.2×0.8

Stop/Start

Press and adjust the switch spot to run the peristaltic pump; close switch spot(port 3  & port 5 short circuit) to shut down the pump

Direction control

Switch control the touch pot for start operation, peristaltic pump run; close switch spot(port 4&port 5 short circuit), peristaltic pump run at anticlockwise direction

Power supply

11.4-25.2V DC Or 100-240V AC 50/60Hz

11.4-25.2V DC；or 100-240V AC（match different power adapter）  50/60Hz

Operation condition

temperature:0℃-40℃, Relative humidity: ＜80%

Weight

1200g

Model

Pump head roll QTY

Optional channel

Tube

Speed range

（RPM）

Flow range（mL/min）

Recommend

S100-2B+DG-1A

S100-2B+DG-2A

S100-2B+DG-4A S100-2B+DG-6A

6

1,2,4，6

0.6×1

≤100

0.003-3.27

cy micro flow, slight higher flow rate

1×1

0.007-6.79

2×1

0.02-20.17

3×1

0.04-38.89

S100-2B+DG-1B

S100-2B+DG-2B

S100-2B+DG-4B

S100-2B+DG-6B

10

1，2，4，6

0.6×1

≤100

0.003-2.64

suitable for lower volume high accuracy filling,lower impulse

1×1

0.006-6.04

2×1

0.017-17.02

3×1

0.028-28.97
