Model

BT300-1F Dispensing type Peristaltic Pump

CPU

ARM Cortex-0 Core,STM32 Chip

Motor drive chip

SANYO THB6128 drive chip

Speed adjustable range

1-300RPM

Speed resolution

1RPM

Distribute function

liquid Quantitative filling accurately

Dispensing type range

0.1mL-999L

Filling times

1-9999 times

Display function

128×32 Dot matrix LCD display, flow rate and speed display in the same screen

Direction control

Clock-wise/counter clock-wise direction reversible

Operation mode

Rotating code switch combine with  Membrane keypad adjust the speed, also support external signal adjust speed

Full speed function

Full speed button to realize fast filling and drain

Power-down memory function

After power on, running as before

Back suck function

Running under Dispensing type mode, pump reverse a certain angle after stopping, to prevent liquid drip

Calibration function

Flow rate rectify function, convenient and fast ; accuracy ±0.5%

Dispensing type Calibration function

Input filling volume , it rectify the distributed liquid automatically; accuracy ±0.5%

External control function

Different model external control module for Start/Stop, direction, flow rate;

0-5V、0-10V、4-20mA、0-10KHz  4 module for option

Communication function

Optional communication module, RS485 communication control (via Modbus protocol)

Foot switch control

Optional

Bracket

Optional (for installing the nozzle)

Nozzle

Various specification nozzle for option, nozzle inner diameter 2.2mm、2.5mm、3mm、4mm、6mm

Power consumption

50W

Power supply

Wide AC90-260V，50Hz/60Hz

Operation condition

Temperature 0 to 40 °C, Relative humidity < 80%

Driver weight

4.8KG

IP rate

IP31

Filling

volume

Filling time (Sec)

Accuracy

Recommend driver

Recommend

pump head

Recommend tube

10 mL

≥0.80

±1.0%

BT300-1F

YZ15

25#

20 mL

≥1.57

±0.8%

25#

30 mL

≥2.39

±0.5%

25#

50 mL

≥2.70

±0.5%

BT600-1F

YZ15

25#

100mL

≥3.25

±0.4%

17#

Driver

Pump head

Pump head roller

Pump head QTY

Tube

Speed range（RPM）

Flow range

（mL/min）

BT300-1F

YZ15

3

1,2

13#

1-300

0.08-23

14#

0.27-88.6

19#

0.52-165.3

16#

0.86-270.9

25#

1.8-558.3

17#

3.2-968

18#

4.1-1343

YZ25

3

1,2

15#

1-300

1.7-530

24#

2.9-871

BZ15-14

3

1,2

14#

1-300

0.23-88.8

BZ15-16

16#

0.79-270.9

BZ25A

24#

2.5-871
