Model

BT600-1L Flow type Peristaltic Pump

CPU

ARM Cortex-0 Core,STM32 Chip

Motor drive chip

SANYO THB6128 drive chip

Speed adjustable range

0.1-600RPM

Speed resolution

0.1（＜100RPM），1（≥100RPM）

Display function

128×32 Dot matrix LCD display, flow rate and speed display in the same screen

Direction control

Clock-wise/counter clock-wise direction reversible

Operation mode

Rotating code switch combine with  Membrane keypad adjust the speed, also support external signal adjust speed

Full speed function

Full speed button to realize fast filling and drain

Power-down memory function

After power on, running as before

Calibration function

Flow rate rectify function, convenient and fast

External control function

Different model external control module for Start/Stop, direction, flow rate;

0-5V、0-10V、4-20mA、0-10KHz  4 module for option

Communication function

Optional communication module, RS485 communication control (via Modbus protocol)

Output function

Start/Stop, direction output, frequency 0-10KHz OC door output

Foot switch control

Optional

Power

Consumption

70W

Power supply

Wide voltage AC90-260V，50Hz/60Hz

Operation condition

Temperature 0 to 40 °C, Relative humidity < 80%

Driver weight

4.2KG

IP rate

IP31

Driver

Pump head

Roller of the pump head

Channel QTY

Tube

（RPM）

Speed range

Flow range

（mL/min）

BT600-1L

YZ15

3

1,2

13#

0.1-600

0.008-46.10

14#

0.027-178.1

19#

0.052-336.9

16#

0.086-556.2

25#

0.18-1176.6

17#

0.32-2111.6

18#

0.41-2416

YZ25

3

1,2

15#

0.1-600

0.17-1066.6

24#

0.29-1856

BZ15-14

3

1,2

14#

0.1-600

0.023-150

BZ15-16

16#

0.079-489.9

BZ25A

24#

0.25-1630
