Product name

S100(300，600)-2B+YZ15(25) Medium Flow Peristaltic Pump

Pump head

YZ15A(PSF material),YZ25A(PSF material),YZ15B(PPS material),YZ25B(PPS material),YZ15C(6 roller )

Start/Stop

support

Direction control

Clockwise and anticlockwise reversible

Internal speed control

BCD DIP switch adjustable

External speed control

0-10kHz impulse control, or 0-5V,0-10V,4-20mA analog signal control for choice, 0-10KHz for standard

S100-2B+YZ15(25)

Internal speed  range

1-100rpm, 15 levels adjustable, standard configuration: 5,10,15,20,25,30,35,40,45,50,60,70,80,90,100rpm; customize service support

S300-2B+YZ15(25)

Internal speed  range

1-300rpm, 15 levels adjustable, standard configuration: 20，40，60，80，100，120，140，160，180，200，220，240，260，280，300rpm; customize service support

S600-2B+YZ15(25)

Internal speed  range

1-600rpm, 15 levels adjustable, standard configuration:

40，80，120，160，200，240，280，320，360，400，440，480，520，560，600rpm;

customize service support

External control speed range

0-100rpm, speed resolution 0.1rpm, ≥100rpm, colinearity

Communication control

RS485 communication, Modbus communication protocol, communication control can’t be exist together with other external control

Speed deviation

≤±0.5%

Tube available

13#,14#,19#,16#,25#,17#,18#,15#,24#

Stop/Start

Press and adjust the switch spot to run the peristaltic pump; close switch spot(port 3  & port 5 short circuit) to shut down the pump

Direction control

Switch control the touch pot for start operation, peristaltic pump run; close switch spot(port 4 &port 5 short circuit), peristaltic pump run at anticlockwise direction

Power supply

11.4-25.2V DC；or 100-240V AC（match different power adapter）  50/60Hz

Operation condition

temperature:0℃-40℃, Relative humidity: ＜80%

Weight

2000g

Model

Pump head roll QTY

Optional channel

Tube

Speed range

（RPM）

Flow range（mL/min）

S100-2B+YZ15A

S100-2B+YZ15B

3

1，2

13#

≤100

≤7.91

14#

≤28.93

19#

≤54.17

16#

≤87.95

25#

≤183.71

17#

≤325.0

18#

≤460.0

S100-2B+YZ25A

S100-2B+YZ25B

3

1，2

15#

≤100

≤178.99

24#

≤285.0

S300-2B+YZ15A

S300-2B+YZ15B

3

1，2

13#

≤300

≤23.21

14#

≤88.76

19#

≤165.07

16#

≤270.25

25#

≤558.33

17#

≤968.33

18#

≤1343

S300-2B+YZ25A

S300-2B+YZ25B

3

1，2

15#

≤300

≤530.0

24#

≤871.7

S600-2B+YZ15A

S600-2B+YZ15B

3

1，2

13#

≤600

≤46.10

14#

≤178.1

19#

≤336.9

16#

≤556.22

25#

≤1176

17#

≤2111

18#

≤2416

S600-2B+YZ25A

S600-2B+YZ25A

3

1，2

15#

≤600

≤1066

24#

≤1856
