Filling machine
Product model
YZ35-13 Peristaltic pump head
[Product introduction]
Flow range: 460-12000mL/min
Slight adjust for tube Gap via rotary knob
Multi-pump head available
Classic design, widely used
[Selection guide]
Model |
Shell material |
Roller material |
Roller quantities |
Available tube |
Speed （RPM） |
Flow range （mL/min） |
Weight （KG） |
YZ35-13 |
PPS |
304 Stainless steel |
3 |
73# |
≤600 |
≤7800 |
2.0 |
82# |
≤12000 |
[Attention]
Adjust rotary knob of YZ35-13 pump head, clockwise direction increase outlet pressure, anticlockwise direction prolong tube lift-time
YZ35-13-PPS adopt import ticona PPS shell, for most chemical reagent excellent corrosion resistance
[Tube installation ]
Pull the stick as counterclockwise 180°, take out the block
Load the tube between roller and the block
Pull the stick clockwise 180°, the block down, tube card lock the tube, installation finished
